Oldham iTrans 2 User Manual

39
Figure 5-4 Locations of Reed Switches and Push Buttons
Programming Mode Overview
NOTE: Zeroing and calibrating the instrument can be accomplished one of
two ways via programming mode. Zeroing and calibrating (as well as other
programming options) can be entered either from the keypad or non-
intrusively using the magnetic wand. Refer to the sections and subsections
within this chapter for detailed information.
When in the Programming Mode, either via the magnetic wand or keypad
operation, the top line of the main display area shows a status bit and three
data bits. The bottom line of the display shows the timers (see Figure 5-5).
The decimals on the far right of each line of the display are channel
indicators. The top decimal indicates channel 1 is being programmed, and
the bottom decimal indicates channel 2.
