Oldham iTrans 2 User Manual

56
Addr
Inst
R/W
Host
R/W
Range
Description
$0107 = 1 decimal place for gas type HCN
$0002 = 0 decimal places for gas type H
2
S
$0206 = 2 decimal places for ClO
2
40105
W
R/W
$0000 to $FFFF
Instrument Mode
Holds code for current mode of
instrument. Possible working modes of
instrument are listed below.
$0001 Normal
$0002 Calibration
$0003 Warm-up
$0006 Zeroing
$0008 Fault
$0009 Reset
Examples:
Sensor in zero fault = $0008
Sensor zeroing = $0006
40106
W
R
$0000 to $FFFF
Status Bits
Holds 16 bits of status for various
parameters in the instrument. A bit value
of “1” indicates that the associated fault
condition is present.
Bit 15 = current loop open
Bit 14 = current loop shorted
Bit 13 = power fault
Bit 12 = 5 volt fault
Bit 11 = missing sensor
Bit 10 = (not defined)
Bit 6 = configuration fault
Bit 5 = zero fault
Bit 4 = calibration fault
Bit 3 = over-range
Bit 2 = failed sensor
Bit 1 = high alarm
Bit 0 = low alarm
Examples:
Missing sensor = Bit 11 is set =
$0800
Power fault and
failed sensor = Bits 13 and 2 set =
$2004
