Getting Started4
Reference Part Description
1 Paper guide Guides the paper as it is fed into the printer.
2 Automatic sheet feeder Automatically feeds the paper into the printer for printing.
3 Automatic document
feeder
Automatically feeds the original document to be printed, scanned or
faxed.
4 Document tray Collects the original documents after use by the automatic document
feeder.
5 Scanner glass cover Protects the scanner glass. Comprises the automatic document feeder.
6 Paper output tray An extendible tray that collects the printed paper as it is output from
the printer.
7 Keyboard Provides the keys to switch the printer on and off, and for all the
selection and send operations.
8 PictBridge/DPOF
compatible USB interface
Allows the USB cable of a compatible digital camera or external
memory devices to be connected.
9 Scanner glass Surface on which documents are placed for scanning or copying.
10 High-speed USB
interface
Allows connection of the USB cable (not supplied) so the printer can be
used with a computer.
11 Power connector Printer power supply connector. Connect the plug of the external
power supply unit to the printer. See "LEDS on the Printer Front Panel".
12 External power supply
unit
Supplies the printer with electrical current. Connect the power cable to
the electrical outlet.
13 RJ11 Connector Telephone signal input line (LINE IN).
14 RJ11 Connector Telephone signal output line (LINE EXT), to connect a telephone or an
answering device.
15 Ink cartridge carrier Holds two ink cartridges. The colour cartridge is inserted on the right,
the black cartridge (or photo cartridge, sold separately) is inserted on
the left.
For replacing the cartridges, see "Replacing the Ink Cartridges".
To access the carrier, with both hands raise the upper part of the
printer. The support lever automatically blocks the upper part of the
printer in the open position.
16 Storage/protection
garage for black and
photo ink cartridges
Stores and protects the black or photo cartridge when not being used.
