Using the Printer with a Computer 29
PHONE/FAX Mode
After a certain number of rings (modifiable selecting Toolbox > Settings > Fax settings > Installation > Reception),
the printer connects to the telephone line and is able to detect if the incoming call is a fax or voice call.
In the cae of a voice call, the printer’s ring tone changes (after the default number of rings), and it rings for the time
defined by Fax/tel timer (modifiable selecting Toolbox > Settings > Fax settings > Installation > Reception), to
allow the call to be answered. If the call is not answered, it is returned to the printer. In the case of a fax call, it is
received and printed.
ANSWERING DEVICE/FAX Mode
The answering device must be connected to the printer.
In this Reception mode, the number of rings preceding intervention of the answering device (see the answering device’s
manual), must be less than that (modifiable selecting Toolbox > Settings > Fax settings > Installation > Reception)
after which the incoming call is received by the printer; in this way the answering device receives the line first. Even
when the call is answered by the answering device, the printer modem is able to recognise if it is a Voice or Fax call. In
the case of a Voice call it does not intervene, otherwise it receives and prints the fax.
Note: If an answering device is connected to the printer, the Reception mode selected must be
ANSWERING DEVICE/FAX.
Service
Reserved information is provided on the fax module for use by service engineers. The list contains the hardware and
software adjustment data for the printer
Note: The data listed must not be changed. To be used exclusively by the field engineering service.
SENDING A FAX USING THE COMPUTER
A fax can be sent from the Toolbox application, either placing the originals on the scanner glass or in the automatic
document feeder, and then using the Send Fax from File function.
Sending a Fax From the Scanner Glass Using the Toolbox Application
1 From the Toolbox application, select Scan to fax.
Raise the scanner glass cover and place the document or the photo on the glass, with the side to be scanned face
down. Make sure that the upper left corner of the document or photo is aligned with the upper left corner of the
scanner glass.
2 The scanner driver interface is automatically displayed on the computer screen, and provides a low resolution
preview of the image (the number of pixels in the image are indicated below the preview). If necessary, modify the
characteristics of the previewed image to obtain the final image you desire using the special tools available (for
example, rotate image, flip image along the vertical/horizontal axes, enlarge or reduce image).
3 Open the Standard tab and select the scan settings:
•
Typ e:
select the type of document to be scanned and select the appropriate button:
Tex t
(black text or graphics),
Mixed
(a combination of black text, colour graphics or photos) or
(colour photos only).
•
Colour:
select the colour scale of the document or the photo to be scanned and select the appropriate button:
Colour
(scan in full colour at 600 dpi),
Grey
(scan in grey shades at 300 dpi) or
B/W
(scan in black and white at 150 dpi).
4 Open the Custom tab and select the scan parameters:
•
Resolution:
select the scan resolution from the pull-down list.
The following resolution is available: 200 dpi.
Note: To send a document in fax mode, it is not necessary to use high resolutions.
•
Colour depth:
from the pop-up, select the number of colours that are represented by the number of bits. The
following values are available: 1-bit, 8-bit or 24-bit (B/W, grey shades, colour).
•
Adjust the
Brightness
and
Contrast
of the document or the photo to be scanned. Move the brightness cursor
towards the right to lighten the image or towards the left to darken it. Move the contrast cursor towards the right to
increase contrast, or towards the left to reduce it.
In both cases, a central position corresponds to a medium setting.
•
Select the
Descreen
check box (remove background) to activate a filter for making the background of the image
uniform, for example, when scanning the pages of a newspaper.
