Olympus BX43 - Controls

7
BX43
Low Magnification Condenser
U-LC
LS30 Adapter
U-LS30ADP
Swing-out Condenser
U-SC3
Halogen Lamp Socket
U-LS30-5
Auxiliary lens mounting
tool (for BX53)
Auxiliary lens
* The auxiliary lens is mounted on the lamp adapter when the U-LC is used. (Page 34)
Top lens swing-out
knob
Top lens
Aperture iris diaphragm
ring (Page 12)
Condenser mount
dovetail
<<Modules for halogen lamp operation>>
Lamp cable
Power Supply Unit
TL4
Brightness control
knob
Main switch
I : ON
: OFF
Lamp socket connector
Guide pins
Guide pin holes
