Olympus BX43 - SPECIFICATIONS

30
8
SPECIFICATIONS
Item Specification
1. Optical system UIS2 (UIS) optical system (featuring infinity correction)
2. Illumination Built-in transmitted Koehler illumination
FN (Field Number): 26.5 (super-widefield compatible)
LED illuminator (continuously variable): U-LHLEDC
Power consumption: 0.5 A
Optional 6V 30W halogen bulb (continuously variable)
Power supply unit TL4: 100-120/220-240 V
$
, 0.85/0.45 A, 50/60 Hz.
Power consumption: 45 W
3. Focusing mechanism Stage up-down movement by roller guide (rack & pinion)
Stroke per rotation: 0.1 mm (fine), 17.8 mm (coarse)
Full stroke range: 25 mm
Upper coarse adjustment limit stopper
Tension adjustment on coarse focus adjustment knob.
4. Revolving nosepiece Type
BX43-5RES U-D6RE
5-position revolving nosepiece with
readout function
Universal 6-position revolving nosepiece
Attachable
module
Transmitted light DIC slider
Transmitted light analyzer
5. Observation tube Type
U-BI30-2 U-TBI-3/U-TBI3-CLI U-TR30-2 U-SWTR-3
Widefield binocular
Widefield, tilting
binocular
Widefield,
trinocular
Super- widefield,
trinocular
Field No. 22 26.5
Tube
inclination
30°
5-35°
(continuously variable)
30°
Interpupillary
distance
adjustment
50-76 mm
Light path
selection Not available
3 steps: @ Binocular 100%
2 Bi 100%, Cam 80%
3 Camera 100%
6. BX stage Type
U-SVRB-4 U-SVLB-4
Coaxial knobs on bottom right. Coaxial knobs on bottom left.
Rectangular ceramic-coated, wire-driven stage
Size 156 mm (D) x 191 mm (W)
Movement
mechanism
X- and Y-axis knob with adjustable tension. Movement range: 52 mm in vertical (Y)
direction, 76 mm in horizontal (X) direction.
Slide holder
(single-slide
holder)
U-HLST-4 (Thick type)
U-HLS-4 (Thin type)
Slide holder
(double-slide
holder)
U-HLDT-4 (Left-opening, thick type)
U-HLD-4 (Left-opening, thin type)
U-HRDT-4 (Right-opening, thick type)
U-HRD-4(Right-opening, thin type)
