FLOW OF OBSERVATION
} When the LED lamp is used and the LIM is set, the LED brightness adjustment knob is defeated.
} When the halogen bulb is used, set the LBD filter in the filter mount on the base (or in the U-FC filter cassette).
(Controls Used) (Page)
Set the main switch to “ I ” (ON) and adjust
the brightness.
@Main switch
2LED brightness
adjustment knob
*
Select the light path (trinocular tube).
5Light path selector knob (P. 22)
Place the specimen on the stage.
6Slide holder (P. 19)
7X-/Y-axis knobs (P. 20)
Engage the 10X objective in the light path.
8Revolving nosepiece
Bring the specimen in focus.
9Coarse/fine adjustment knobs (P. 17)
Adjust the interpupillary distance.
Adjust the diopter.
Adjust the light axis.
aBinocular tube (P. 21)
bDiopter adjustment ring (P. 21)
cCondenser height adjustment knob (P. 24)
dCondenser centering knob (P. 12)
Adjust the aperture iris and field iris diaphragms.
eAperture iris diaphragm ring (P. 12)
fField iris diaphragm ring (P. 12)
Engage the desired objective in the light path
and bring the specimen in focus.
8Revolving nosepiece
Insert the required filters.
gFilter mount (P. 14)
Adjust the brightness.
2LED brightness
adjustment knob
*
Start observation.
LED lamp Halogen bulb
3Main switch
|Brightness
adjustment knob
(P. 13)
|Brightness
adjustment knob
(P. 13)
* The LED brightness adjustment knob is defeated when the LIM is set (see page 34).
