Fig, 13
Fig
. 14
Fig. 15
•
BX50
When using the trinocular observation tube (U-TR30)
or
super
-w
ide
angle t(inocular observation
tube
(U-SWT
A)
When
uSing
a fin
der
eyepiece or
an
eyepiece w ith diopter adjustment.
inset
it
Into the righi-hand eyepiece sleeve.
When
doing so, make sure
that the eyepiece positioning
pin@fits
IntO
the
notch@at
the boltom
of
the eyepiece sleeve. (Fig.
13)
• Conn
ec
t the Power Cord
(Fig. 14)
1.
Check
that
the main switch
CD
is
in
the
OFF
position.
2. Before shipment from the factory, the voltage selector switch @
is
set to the
2QO-240V
position. In case your local line voltage
is
100-
120V,
move
the lever
to
the 1OD-120V position using a flat-blade
screwdriver.
3.
Plug
the power cord into the receptacle @'
4. Connect the power cord's ground wire to the ground terminal on the
power outlet you
will
be
USing with the microscope, then plug the
power cord into the
wall outlet.
a Replace
Fu
ses
(FigS
. 15,16)
Before replacing fuses, turn off the power switch
and
unplug the power
eo<d
.
1. Remove the fuse holder
CD
by squeezing it at the sides
and
pulling
outward.
(Fig.
15)
2. Replace both fuses
<1>
with
new
ones.
(Fig
. 16)
* Use
on
ly fuses
of
the specified rating.
Fuse
rating: 250V 5A Time
Lag.
Hi-breaking-Capacity
(UnelFuse 215005)
6
