Olympus E-PL1 User Manual

2 EN
Unpack the box contents
The following items are included with the camera.
If anything is missing or damaged, contact the dealer from whom you purchased
the camera.
Camera
AV cable
(Monaural)
CB-AVC3
USB cable
CB-USB6
PS-BCS1(BCS-1)
Lithium ion charger
PS-BLS1(BLS-1)
Lithium ion battery
StrapBody cap
Computer software (ib)
CD-ROM
Instruction manual
Warranty card
•
•
•
1 Thread the strap in the
direction of the arrows.
2 Lastly, pull the strap tight
making sure that it is
fastened securely.
1
2
3
Attach the other end of the strap to the other eyelet in the same way.•
Attaching the strap
Indications used in this manual
The following symbols are used throughout this manual.
# Caution
Important information on factors which may lead to a malfunction
or operational problems. Also warns of operations that should be
absolutely avoided.
$ Notes
Points to note when using the camera.
% Tips
Useful information and hints that will help you get the most out of
your camera.
g
Reference pages describing details or related information.
S0027E.indb2S0027E.indb2 2009/12/2114:52:352009/12/2114:52:35

Olympus E-PL1 Specifications

General

Camera Type	Mirrorless
Model	E-PL1
Sensor Type	Live MOS
Effective Pixels	12.3 megapixels
Image Stabilization	Sensor-shift
ISO Sensitivity	100-3200
Lens Mount	Micro Four Thirds
Shutter Speed	60-1/2000 sec
Continuous Shooting	3 fps
LCD Screen Size	2.7 inches
LCD Screen Resolution	230, 000 dots
Video Format	AVI Motion JPEG
Storage Media	SD/SDHC
Battery	BLS-1 lithium-ion battery
Image Processor	TruePic V
Sensor Size	17.3 x 13.0 mm (Four Thirds)
Weight	296 g
Viewfinder	Optional (VF-2)
Video Recording	HD (1280 x 720)
