46
Chapter 2 Nomenclature and functions
OLYMPUS CAPSULE ENDOSCOPE SYSTEM
2.7 Real time viewer cable (MAJ-1485)
1. Real time viewer cable
Connects the real time viewer to the recorder unit, and transfers image
signals between them.
2. Connectors
Connect to the real time viewer cable connectors on the recorder unit and
the real time viewer. To disconnect, push in the buttons on the side.
2.8 Recorder unit cradle cable
1. Recorder unit cradle cable
Connects the recorder unit cradle to the workstation, and transfers data
between the recorder unit and the workstation.
2. Connectors
Connect to the USB connector on the workstation, and to the recorder unit
cradle cable connector on the recorder unit cradle.
1. Real time viewer cable
2. Connectors
1. Recorder unit cradle cable
2. Connectors
