Olympus EndoCapsule - Battery Pack (MAJ-1473)

48
Chapter 2 Nomenclature and functions
OLYMPUS CAPSULE ENDOSCOPE SYSTEM
2.10 Battery pack (MAJ-1473)
1. Positive (+) terminal
Outputs positive voltage.
2. Connector
Connects to the connector in the battery pack slot of the receiver/real time
viewer. Also connected to the connector in the battery pack slot of the
recharger.
3. Negative (–) terminal
Outputs negative voltage.
3. Negative (–) terminal
1. Positive (+) terminal
2. Connector
(as seen from “A”)
A
