4.3 Nomenclature and functions of the main screen
The following screen is displayed after login, and is used for observing images
downloaded from the recorder unit.
Figure 4.10
7. Logoff button
5. Menu bar4. Recorder button
3. List button
2. Report button
1. Export button
6. Image display area
8. Image operation buttons
11. Time bar
12. Average color bar
13. Red color detection bar
9. Thumbnail view
10. Time display
14. Antenna display
15. Antenna button
