Olympus GX41 - Specifications

GX41
19
SPECIFICATIONS
Item Specifications
1. Optical system UIS2 (UIS) (Universal Infinity System) optics
2. Illumination system
6V30WHAL-L long-life halogen bulb.
Hosobuchi G4 20H CF-6.
(Average bulb life: Approx. 2000 hrs.
under rated use)
6V30WHAL high-intensity halogen bulb.
Philips Type 5761.
(Average bulb life: Approx. 100 hrs.
under rated use)
Output rating: 6 V DC, 30 VA
Input rating: 100-120/220-240 V AC, 0.85/0.45 A, 50/60 Hz.
3. Focusing mechanism
Vertical movement of revolving nosepiece (Stage is fixed.)
Coarse/fine adjustment knobs (provided with tension adjustment mechanism).
Stroke (from focal point on stage surface): 7 mm upward and 2 mm downward.
4. Revolving nosepiece Quadruple-position revolving nosepiece (Fixed)
5. Observation
tubes
Binocular tubes
U-CBI30-2: Field number 20, tube
inclination 30°, interpupillary distance
adjustment range 48-75 mm.
U-BI30-2: Field number 22, tube
inclination 30°, interpupillary distance
adjustment range 50-76 mm.
Trinocular tubes U-CTR30-2: Field number 20, tube
inclination 30°, interpupillary distance
adjustment range 48-75 mm, light
intensity ratio between binocular and
straight tubes fixed (at 50:50).
U-TR30-2: Field number 22, tube
inclination 30°, interpupillary distance
adjustment range 50-76 mm, light
intensity ratio between binocular and
straight tubes variable in 3 steps (100:0,
20:80, 0:100).
Tilting tubes U-CTBI: Field number 18, tube inclination
30-60°, interpupillary distance adjustment
range 48-75 mm. 10X eyepieces are fixed
and not exchangeable.
U-TBI-3: Field number 22, tube inclination
5-35°, interpupillary distance adjustment
range 50-76 mm.
Only WH10X eyepieces can be used.
CKX-TBI: Field number 20, tube
inclination 30-60°, interpupillary distance
adjustment range 50-76 mm. WHB10X
eyepieces are provided and not
exchangeable.
6. Eyepieces WHB10X, WHB10X-H:
Field number 20. Eyepiece micrometer
disk acceptable.
WHN10X, WHN10X-H:
Field number 22. Eyepiece micrometer
disk acceptable.
7. Objectives MPlan5X/10X/20X/40X/50X/100X.
8. Stage Stage dimensions 160(W) x 250(D) mm
9. Mechanical stage Transversing area: 120(X) x 76(Y) mm.
Coaxial low drive control knobs attachable on right or left side of plain stage.
Provided with stage plate holder, slide glass holder and stage plate.
10. Dimensions and weight 236(W) x 624(D) x 407(H) mm (when a binocular tube is mounted). Approx. 10 kg
(22 lbs).
11. Operating Environment · Indoor use.
· Altitude: Max. 2000 meters.
· Ambient temperature:5° to 40°C (41° to 104° F).
· Relative humidity:85% for temperatures up to 31°C (88°F), decreasing linearly through
70% at 34°C (93°F), 60% at 37°C (99°F) to 50% relative humidity at 40°C (104°F).
· Supply voltage fluctuations: ±10%.
· Pollution degree: 2 (in accordance with IEC60664).
· Installation (overvoltage) category: II (in accordance with IEC60664)
