Olympus GX41 - Nomenclature

GX41
3
1
NOMENCLATURE
Objective
· MPLN5X to 100X
· MPlan5X to 100X
Eyepiece
Microscope Frame
GX41F
Lamp socket
Observation tube
Stage plate
CK40M-CP
Mechanical stage
CK40-MVR
U-LS30-4
}The modules shown below are examples of those used in a typical system. Certain modules are usable even when they are not
mentioned below. For these modules, refer to the latest catalogues or contact Olympus.
Stage Center Plate
· GX-CP
· IX2-GCP
· IX-CP50
· U-CBI30-2
· U-BI30-2
· U-CTR30-2
· U-TR30-2
· U-CTBI
· U-TBI-3
· CKX-TBI
· WHB10X
· WHB10X-H
· WHN10X
· WHN10X-H
Intermediate Attachment
} Remove the observation tube mount and
attach the GX41-EPA to attach an interme-
diate attachment (see page 24).
· U-CA
· GX-SPU
· U-EPA2
· U-ECA
· U-DA
· U-DO3
4-position revolving
nosepiece (Fixed)
Stage (Fixed)
