31
GX53
4-2 Reflected light simple polarization observation
When performing the sensitive color observation, combine the polarizer (GX-POTP).
Select the observation light path.
Place a sample on the stage.
Engage the 10X objective in the light path.
Bring the sample into focus.
Set the analyzer and the polarizer.
Adjust the interpupillary distance.
Adjust the diopter.
Adjust the aperture diaphragm and the field diaphragm.
Adjust the brightness.
Adjust the brightness.
Engage the objective with the magnification to be used
in the light path and bring the sample into focus.
Observation
Select the brightfield (BF) observation.
Set the main switch to (ON).
Stage plate P.19
X-axis/Y-axis knobs P.19
Revolving nosepiece P.20
Main switch P.16
BF/DF selection lever P.17
Eyepiece/camera light path selection
knob
P.18
Operation part Page
Analyzer insertion slot P.35
Polarizer insertion slot P.35
Brightness control knob P.22
Aperture diaphragm lever P.26
Field diaphragm lever P.27
Interpupillary distance adjustment scale P.23
Diopter adjustment ring P.23
Brightness control knob P.22
Revolving nosepiece P.20
Coarse/Fine focusing knobs P.21
Coarse/Fine focusing knobs P.21
Light path selection knob on trinocular tube
or Observation/SP selection knob on the
side port
To Next Page
