88 Specifications
Configuration units Product name Specifications
Microscope frame GX53F Focusing unit:
Coarse/fine focusing coaxial knob: Stroke 9 mm
(2 mm above and 7 mm below the stage surface)
Fine focusing knob: Movement distance per rotation 100 μm
(One scale: 1 μm)
Coarse focusing knob: Movement distance per rotation 7 mm
Equipped with tension adjustment mechanism and upper limit stopper
mechanism
Rating:
AC adapter:
Input: 100-240V
50-60Hz 0.4A
Output: 5V
2.5A
Microscope frame:
Input: 5V / 2.5A
Dimension: Approx. 509(W) x 843(D) x 507(H) mm
< Combination examples >
Observation tube U-BI90
Lamp housing BX3M-LEDR
Revolving nosepiece U-D6BDRES-S
Stage GX-SVR
Wafer holder GX-CP
Observation
tube
Binocular tube U-BI90 Field number 22
U-BI90CT Field number 22
U-TBI90 Field number 22, tilting type
Trinocular tube U-TR30H-2 Field number 22
Light
source for
reflected light
illumination
LED lamp
housing
BX3M-LEDR White LED: Maximum current: 700 mA
Average lifetime: Approx. 60,000 hours
(designed value in normal operation)
Power supply: Built-in the microscope frame
Halogen lamp
housing
U-LH100L-3 Applicable bulb:
12V100WHAL-L (long life type made by PHILIPS Co. 7724I)
Lifetime: Approx. 2,000 hours (Used in accordance with rating)
12V100WHAL (high light intensity type made by PHILIPS Co. 7023)
Lifetime: Approx. 100 hours (Used in accordance with rating)
Bulb voltage adjustment range:
DC 1.0 V to 12.0 V (Changeable continuously)
Power supply: TH4-100, TH4-200
Mercury lamp
housing
U-LH100HGARO
U-LH100HG
Applicable burner:
USH-103OL (made by Ushio Inc.)
Lifetime: Approx. 300 hours (Used in accordance with rating)
Power supply: U-RFL-T
Light source
for light guide
illumination
U-LGPS Light guide: U-LLG150, U-LLG300
Light guide adapter: U-LLGAD
Light
source for
transmitted
light
illumination
LED lamp
housing
BX3M-LEDT White LED; Maximum current: 700mA
Average lifetime: Approx. 60,000 hours
(designed value in normal operation)
Power supply: BX3M-PSLED
Halogen lamp
housing
U-LH100L-3 Applicable bulb:
12V100WHAL-L(long life type made by PHILIPS Co. 7724I)
Lifetime: Approx. 2,000 hours (Used in accordance with rating)
12V100WHAL (high light intensity type made by PHILIPS Co. 7023)
Lifetime: Approx. 100 hours (Used in accordance with rating)
Bulb voltage adjustment range:
DC 1.0 V to 12.0 V (Changeable continuously)
Power supply: TH4-100, TH4-200
