67
GX53
Attaching two lamp housings
· The attachable lamp housings or adapters are restricted in combinations, orders and directions. Attach
them as shown in the picture below.
· Attach the double lamp housing adapter (U-DULHA) so that the
a
part shown in the following picture
comes to the left side horizontally when facing to the back side of the microscope frame.
a
Adapter
MX-HGAD
Liquid light guide adapter
U-LLGAD
Double lamp housing adapter
U-DULHA
Reflected LED light source
BX3M-LEDR
Halogen lamp housing
U-LH100L-3
Mercury lamp housing
U-LH100HG
U-LH100HGAPO
