Chapter 3 Installation and Connection
21
High definition LCD monitor OEV261H
3.1 Installing the monitor
• The monitor is heavy; care must be taken when installing it.
Otherwise, injury to the installer(s) and/or damage to the
instrument may result.
• When installing the instrument, reserve a space of 10 cm or
larger between the instrument and any walls or other
equipment. Lack of such a space will interferes with the
monitor’s internal cooling and may lead to malfunction or
equipment damage.
• Do not install this monitor near a source of strong
electromagnetic waves (such as a microwave or short-wave
therapy machine, MRI equipment, radio equipment or cellular
phone). Otherwise, electromagnetic noise may interfere with
the monitor image.
Installation on a mobile workstation
When using a LCD monitor mount, prepare a 100 × 200 mm or 100 × 100 mm
monitor mount that complies with VESA mount standards.
Fix the monitor onto a 100 × 200 mm monitor mount using the six screws
provided. Or fix the monitor onto a 100 × 100 mm monitor mount using the four
screws provided. For installation procedures, refer to the instruction manual for
the monitor mount.
