Chapter 3 Installation and Connection
25
High definition LCD monitor OEV261H
2. Slide the supplied DC cord into the DC OUT terminal on the AC adapter until
it is locked in place (see Figure 3.2).
Figure 3.2
3. Slide the DC cord into the DC IN terminal on the monitor until it locks in
place (see Figure 3.3).
Figure 3.3
4. Connect the power cord to the wall mains outlet.
The power cord supplied with this should be connected to the wall mains
outlet or mobile workstation.
