Chapter 5 Screen Menu and Operation of Front Panel
31
High definition LCD monitor OEV261H
PRESET D PRESET E PRESET F
INPUT CONFIG
Video/Y/C AUTO AUTO AUTO
RGB/YP
B
P
R
RGB-VIDEO RGB-VIDEO RGB-VIDEO
SELECT SYNC AUTO AUTO AUTO
COMP.
RGB SQUARE SQUARE SQUARE
HD15 SQUARE SQUARE SQUARE
DVI-D1 DVI-COMP. DVI-COMP. DVI-COMP.
DVI-D2 DVI-VIDEO DVI-VIDEO DVI-VIDEO
VIDEO CONFIG
BACKLIGHT 50 50 50
COLOR TEMP. D93 D65 D65
COLOR MODE of each
input terminal
VIDEO 8-A 8-A 2-A
Y/C 8-A 8-A 2-A
RGB/YP
B
P
R
8-A 8-A 2-A
HD15 6-A 6-A 6-A
SDI1 8-A 8-A 2-A
SDI2 8-A 8-A 2-A
DVI-D1 6-A 6-A 6-A
DVI-D2 8-A 8-A 2-A
SYSTEM CONFIG
MENU POSITION
STATUS DISPLAY 3SEC OFF 3SEC OFF 3SEC OFF
POWER ON SETUP LAST LAST LAST
POWER SAVE MODE OFF OFF OFF
LANGUAGE ENGLISH
LOGO ON ON ON
FUNCTION
FUNCTION1 PORT A GAMMA SELECT PORT A GAMMA SELECT PORT A GAMMA SELECT
FUNCTION2 PORT B GAMMA SELECT PORT B GAMMA SELECT PORT B GAMMA SELECT
FUNCTION DISPLAY ON2 ON2 ON2
WINDOW CONFIG
PIP
PORT A DISPLAY
MODE
NORMAL 5:4 5:4
PORT B DISPLAY
MODE
4:3 SQUARE 5:4
DISPLAY POSITION
POP
PORT A DISPLAY
MODE
NORMAL 5:4 5:4
PORT B DISPLAY
MODE
4:3 SQUARE 5:4
DISPLAY POSITION MODE1 MODE1 MODE1
DISPLAY PATTERN PORT A PORT A PORT A
SQUARE PATTERN MODE1 MODE1 MODE1
REMOTE CONFIG
GPI CONTROL ENABLE DISABLE ENABLE
GPI1 PORT A INPUT VIDEO PORT A INPUT SDI1 PORT A INPUT SDI1
GPI2 PORT A INPUT Y/C
PORT A INPUT RGB/YP
B
P
R
PORT A INPUT RGB/YP
B
P
R
GPI3
PORT A INPUT RGB/YP
B
P
R
PORT A INPUT VIDEO PORT A INPUT VIDEO
GPI4 UNDEF PORT A INPUT Y/C PORT A INPUT Y/C
GPI5 UNDEF UNDEF UNDEF
GPI6 UNDEF UNDEF UNDEF
GPI7 UNDEF UNDEF UNDEF
GPI8 UNDEF UNDEF UNDEF
CONTROL
CONTROL LOCK ON ON ON
FRONT LOCK MENU MENU MENU
INPUT
PORT A SDI1 SDI1 SDI1
PORT B RGB SDI2 DVI-D1
