Chapter 6 Submenu Operations
45
High definition LCD monitor OEV261H
Selecting an item where appears in the value field
A list of additional submenus appears.
Submenu Description
VIDEO/ Y/C Selects the format of signals input to the VIDEO, Y and C input terminals.
• AUTO Automatically selects NTSC or PAL.
•NTSC Selects NTSC.
• PAL Selects PAL.
RGB/YP
B
P
R
Selects RGB or YP
B
P
R
input.
•YP
B
P
R
Selects the YP
B
P
R
signal.
• RGB-VIDEO Selects the video RGB signal.
• RGB-COMP. Selects the COMP. RGB signal.
SELECT SYNC Selects the synchronizing signal when using YP
B
P
R
and RGB-VIDEO input.
• AUTO Automatically detects the synchronizing signal (G-ON has priority)
• INT Selects the synchronizing signal superimposed on the Y signal for YP
B
P
R
input
and the synchronizing signal superimposed on the G signal for RGB-VIDEO input.
• EXT External synchronization
When GPI of EXT is enabled and the item is assigned, the item appears gray to indicate that
selection is disabled and the set GPI value appears.
COMP. Sets up a connection to a computer (COMP.).
∗ Enabled only for RGB-COMP. and HD15 inputs.
Switches between values set for each input terminal.
∗ Enabled only during one screen display in PC input.
Select and press [ENTER] to open the COMP. submenu (page 46).
RGB Switches between the WIDE and normal screen for RGB-COMP. signal of RGB-input-terminal.
• WIDE Shows the WIDE screen.
• SQUARE Shows the normal screen.
HD15 Switches between the WIDE and normal screen for signal of the HD15-input-terminal.
• WIDE Shows the WIDE screen.
• SQUARE Shows the normal screen.
DVI-D1 Selects the format of signals input to the DVI-D1 input terminal.
• DVI-VIDEO Selects component input.
• DVI-COMP. Selects COMP. input.
DVI-D2 Selects the format of signals input to the DVI-D2 input terminal.
• DVI-VIDEO Selects component input.
• DVI-COMP. Selects COMP. input.
Fiber adapter is connected to this DVI-D2 terminal.
