Chapter 6 Submenu Operations
High definition LCD monitor OEV261H
COLOR MODE 5
ITEM A B C D E F G H I J
RED 30303030303030303030
GREEN30303030303030303030
BLUE 30 30 30 30 30 30 30 30 30 30
GAMMA
SELECT
ENDOSCOPE ENDOSCOPE ENDOSCOPE ENDOSCOPE ENDOSCOPE ENDOSCOPE ENDOSCOPE ENDOSCOPE ENDOSCOPE ENDOSCOPE
SCAN SIZE HD MODE6 MODE6 MODE6 MODE6 MODE6 MODE6 MODE6 MODE6 MODE6 MODE6
SCAN SIZE SD MODE2 MODE2 MODE2 MODE2 MODE2 MODE2 MODE2 MODE2 MODE2 MODE2
MONO OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF
PHASE 30 30 30 30 30 30 30 30 30 30
CHROMA 25 25 25 25 25 25 28 28 22 22
BRIGHT 30 30 30 30 30 30 30 30 30 30
CONTRAST 50 50 50 44 44 44 44 44 50 50
SHARPNESS
MODE
HIGH LOW HIGH HIGH LOW HIGH LOW HIGH LOW HIGH
SHARPNESS H 0 7 10 0 7 10 7 10 7 10
SHARPNESS V 0 7 10 0 7 10 7 10 7 10
COLOR MODE 6
ITEM A B C D E F G H I J
RED 30303030303030303030
GREEN30303030303030303030
BLUE 30 30 30 30 30 30 30 30 30 30
GAMMA
SELECT
2.2 2.2 2.2 2.2 2.2 2.2 2.2 2.2 2.2 2.2
SCAN SIZE HD MODE3 MODE3 MODE3 MODE3 MODE3 MODE3 MODE3 MODE3 MODE3 MODE3
SCAN SIZE SD MODE2 MODE2 MODE2 MODE2 MODE2 MODE2 MODE2 MODE2 MODE2 MODE2
MONO OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF
PHASE 30 30 30 30 30 30 30 30 30 30
CHROMA 25 25 25 25 25 25 28 28 22 22
BRIGHT 30 30 30 30 30 30 30 30 30 30
CONTRAST 50 50 50 44 44 44 44 44 50 50
SHARPNESS
MODE
HIGH LOW HIGH HIGH LOW HIGH LOW HIGH LOW HIGH
SHARPNESS H 0 7 10 0 7 10 7 10 7 10
SHARPNESS V 0 7 10 0 7 10 7 10 7 10
