72
Chapter 6 Submenu Operations
High definition LCD monitor OEV261H
GPI1-8 Assigns REMOTE control terminal pins. The same item can be set to each of the GPI terminals.
For details, refer to the REMOTE specifications of the GPI terminal on page 75.
• UNDEF (default value)
• PORT A SCAN SIZE MODE3
*1
• PORT A SCAN SIZE MODE5
*1
• PORT A SCAN SIZE MODE7
*1
• PORT B SCAN SIZE MODE3
*1
• PORT B SCAN SIZE MODE5
*1
• PORT B SCAN SIZE MODE7
*1
•PIP
•POP
•FLIP
• SELECT SYNC
*1
•RED TALLY
•GREEN TALLY
• PORT A INPUT VIDEO
• PORT A INPUT Y/C
• PORT A INPUT RGB/YP
B
P
R
• PORT A INPUT HD15
• PORT A INPUT SDI1
• PORT A INPUT SDI2
• PORT A INPUT DVI-D1
• PORT A INPUT DVI-D2
• PORT B INPUT VIDEO
• PORT B INPUT Y/C
• PORT B INPUT RGB/YP
B
P
R
• PORT B INPUT HD15
• PORT B INPUT SDI1
• PORT B INPUT SDI2
• PORT B INPUT DVI-D1
• PORT B INPUT DVI-D2
∗1: When the same INPUT is selected for both PORT A and B, both PORT A and B comes
available.
Submenu Description
