Chapter 7 REMOTE Specifications
High definition LCD monitor OEV261H
PORT B SCAN SIZE MODE3 Switches PORT B scan size.
Level operation:
∗4
Connected: MODE3, Open: OFF
PORT B SCAN SIZE MODE5 Switches PORT B scan size.
Level operation:
∗4
Connected: MODE5, Open: OFF
PORT B SCAN SIZE MODE7 Switches PORT B scan size.
Level operation:
∗4
Connected: MODE7, Open: OFF
PIP Switches the PIP mode.
Edge operation:
∗3
Switches screen modes:
PORT A → PIP1 → PIP2 → ...
POP Switches the POP mode.
Edge operation:
∗3
Switches screen modes:
PORT A → POP1 → POP2 → ...
FLIP Switches the FLIP mode.
Edge operation:
∗3
Switches screen modes:
Normal → Upside-down → Reverse
→ ...
SELECT SYNC Switches synch signals. Level operation:
Connected: EXT, Open: G-ON
RED TALLY Lights the red tally. Level operation:
Connected: ON, Open: OFF
∗1
GREEN TALLY Lights the green tally. Level operation:
Connected: ON, Open: OFF
∗1
PORT A INPUT VIDEO Switches PORT A input system to
VIDEO.
Level operation:
Connected: ON, Open: OFF
∗2
PORT A INPUT Y/C Switches PORT A input system to Y/C. Level operation:
Connected: ON, Open: OFF
∗2
PORT A INPUT RGB/YP
B
P
R
Switches PORT A input system to
RGB/YP
B
P
R
.
Level operation:
Connected: ON, Open: OFF
∗2
PORT A INPUT HD15 Switches PORT A input system to HD15. Level operation:
Connected: ON, Open: OFF
∗2
PORT A INPUT SDI1 Switches PORT A input system to SDI1. Level operation:
Connected: ON, Open: OFF
∗2
PORT A INPUT SDI2 Switches PORT A input system to SDI2. Level operation:
Connected: ON, Open: OFF
∗2
PORT A INPUT DVI-D1 Switches PORT A input system to
DVI-D1.
Level operation:
Connected: ON, Open: OFF
∗2
Assigned item Function Operating conditions
