High definition LCD monitor OEV261H
Output
Video signal output:
VIDEO output
terminal
BNC (×1) loop through, with automatic 75 Ω
termination
Y/C output terminal 4-pin mini-DIN (×1) active through out
YP
B
P
R
/RGB output
terminal
BNC (×3) loop through, with automatic 75 Ω
termination
SYNC/HD output
terminal
BNC (×1) loop through, with automatic 1 kΩ
termination
VD output terminal BNC (×1) loop through, with automatic 1 kΩ
termination
SDI1, 2 output
terminal
BNC (×2) active through out
HD15 output
terminal
D-SUB 15-pin (×1) switched out
DVI-D1, 2 output
terminal
DVI-D (×2) switched out
DC power supply
output:
DC OUT 5V, 1A
Storage of settings
Settings are stored if LAST is selected as the
value of [POWER ON SETUP] in SYSTEM
CONFIG submenu when the power switch is
turned off.
