Appendix
ELECTROSURGICAL UNIT PSD-30
Item Specification
Classification
(electromedical
equipment)
Type of
protection
against electric
shock
Class I (3 pin power cord)
Degree of
protection
against electric
shock
TYPE CF (the patient leakage current below
10 µA)
Note: Direct application to the heart should not
be attempted as spark discharge during
electrosurgery may affect the cardiac function
of the patient (refer to dangers, warnings and
cautions and EN standard (EN60601-1)).
Degree of
protection
against
explosion
Never use the electrosurgical unit where there
is a risk of flammable gases.
Additional Defibrillation-protected equipment.
Output circuit Neutral electrode isolated from earth at high
frequency.
Power supply Voltage 220, 230, 240 V
Frequency 50/60 Hz
Input current 2A
Voltage
fluctuation
Within
±10%
Fuse rating 3.15 A, 250 V
Fuse size 5.0 × 20 mm
Size Dimensions 295 mm (W) × 160 mm (H) × 420 mm (L)
Weight 7.8 kg
