Olympus U-MDOB3 - Nomenclature of Units and Functions

7
2 Nomenclature of units and functions
Pointer control lever for assistant observer (page 13)
Power input plug
Power output plug
Pointer color switching lever (page 13)
Up: Red. Middle: Shielded. Down: Green.
Pointer control lever (page 13)
AC adapter
input connector
U-DO3
AC adapter
Tube mount
Tube mount
Pointer brightness control knob (page 13)
OFF/Continuously variable
Face to face observation
system for 2 persons
