3 Operation
1
Diopter adjustment of main observer
3-2 Diopter adjustment
1
a
b
When the eyepiece is equipped with the eyepiece micrometer
While looking through the eyepiece equipped with the eyepiece
micrometer, rotate the diopter adjustment ring
b
to adjust so that
the scales or lines of the eyepiece micrometer in the field of view are
clearly visible. When you rotate the diopter adjustment ring
b
, keep
pressing the lower part
a
of the eyepiece.
Place the specimen.
Engage the 10X objective in the light path. While looking through the
eyepiece equipped with the eyepiece micrometer, rotate the coarse/
fine focusing knobs to bring the specimen into focus.
Rotate the diopter adjustment ring
b
of the eyepiece which is not
equipped with the eyepiece micrometer to bring the specimen into
focus.
1
2
3
4
b
a
3-1 Using the stray light prevention cover
Cover the eyepieces
a
which are not used by the assistant observers
with the provided stray light prevention covers
b
.
1
