3-4 Notes for image acquisition
This section describes special considerations for image acquisition
in combination with discussion attachments.
· When combining the camera, attach the trinocular tube
at the main observer position and attach the camera via
camera adapter.
· If the pointer is in the metering area, the exposure during
image acquisition may be affected. Refer to the instruction
manual for camera in use and set the appropriate
exposure time.
· If eyepieces at assistant observer positions are not
covered with stray light prevention covers, the stray light
entered from eyepieces may appear on the image. During
image acquisition, cover the eyepieces
a
at assistant
observer positions with stray light prevention covers
b
.
You can acquire the image showing the pointer (
) on the
specimen.
