Pointer control lever (page 13)

Stand height lock knob (page 19)

Pointer color switching lever (page 13)

Up: Red. Middle: Shielded. Down: Green.

U-MDOB3

AC adapter

input connector

AC adapter (common with the face to face observation system for 2 persons)

Tube mount

Pointer brightness control knob (page 13)

OFF/Continuously variable

System for 9 persons

input connector

U-MDOSV

Pointer control lever (page 13)

Stand height lock knob (page 27)

Tube mount

Pointer color switching lever (page 13)

Up: Red. Middle: Shielded. Down: Green.

AC adapter (common with the face to face observation system for 2 persons)

Tube mount

Pointer brightness control knob (page 13)

OFF/Continuously variable

System for 10 persons

AC adapter

input connector

Tube mount

U-MDO10R3

U-MDO10B3

U-MDOSV

Tube mount

BX3-MDOE
