5.4 Gas supplying and water feeding
49
UCR INSTRUCTION MANUAL
Ch.5
WARNING
If the gas supply from the endoscopic CO
2
regulation unit cannot be stopped by
pressing the start/stop switch, stop the gas supply by turning the valve of the CO
2
gas cylinder clockwise.
CAUTION
Be sure to stop the gas supply from the endoscopic CO
2
regulation unit before
disconnecting any gas tubes, water container, endoscope, or lens cleaning sheath.
As the gas supply is not designed to automatically stop when disconnection takes
place, replacing the endoscope without stopping the gas flow will not only empty
the CO
2
gas cylinder but may also increase the CO
2
concentration in the
environment.
NOTE
When the endoscopic CO
2
regulation unit is combined with the Gas tube
(MAJ-1741), the Low flow gas tube (MAJ-1742), or Extra low flow gas tube
(MAJ-1816), the gas flow rate is approximately equivalent to that when the airflow
pressure level setting of the light source is set to “High”, “Medium”, and “Low”. For
the standard gas flow rate with different types of endoscopes, refer to the
endoscope’s instruction manual.
5.4 Gas supplying and water feeding
1 Confirm that the gas tube is properly connected according to Section 3.6, “Connecting
the Gas tube (MAJ-1741), Low flow gas tube (MAJ-1742), and Extra low flow gas tube
(MAJ-1816)”.
2 Press the start/stop switch to start gas supply.
3 The gas supply indicator illuminates and the endoscopic CO
2
regulation unit starts
supplying gas.
4 Supply gas or water according to the instruction manual for the endoscope.
5 After the examination, press the start/stop switch again to stop the gas supply.
