App.
Transportation, storage, and operating environments
69
UCR INSTRUCTION MANUAL
Endoscopic CO
2
regulation unit
Transportation, storage, and operating environments
Operating
environment
Ambient temperature 10 – 40°C (50 – 104°F)
Relative humidity 30 – 85%
Atmospheric
pressure
700 – 1060 hPa
Transportation and
storage environment
Ambient temperature –25 to 70°C (–13 to 158°F)
Relative humidity 10 – 90%
Atmospheric
pressure
700 – 1060 hPa
Specifications
Item Specification
Power supply Voltage 100 – 240 V AC
Voltage fluctuation Within ±10%
Frequency 50/60 Hz
Frequency
fluctuation
Within ±1Hz
Input 40 VA
Fuse rating 2 A, 250 V
Fuse size ø5 × 20mm
Size Dimensions 130 (W) × 156(H) × 334 (D) mm (housing dimensions)
Weight 4.9 kg
Applicable gas •CO
2
gas for medical use.
• Connection to gas cylinder via the Olympus cylinder hose
(optional; three hose types available to fit the specific CO
2
gas
cylinders used: MAJ-1080 (PIN), MAJ-1081 (DIN), MAJ-1082
(ISO))
• Connection to medical gas pipeline via the Olympus medical gas
pipeline adapter (MAJ-1084 (NIST), MAJ-1085 (DISS))
• Pressure range of medical gas pipeline
– upper limit: according to ISO 7396 (1400 kPa)
– lower limit: 343.2 kPa (3.5 kgf/cm
2
)
• Hose for medical gas pipeline is required to comply with
ISO 5359 (NIST or DISS)
