App.
72
Specifications
UCR INSTRUCTION MANUAL
 Cylinder hose (DIN, MAJ-1081), Cylinder hose (ISO, MAJ-1082)
 Gas tube (MAJ-1741)
 Low flow gas tube (MAJ-1742)
 Extra low flow gas tube (MAJ-1816)
Item Specification
Hose length 1000 mm
Compatible cylinder
connector
MAJ-1081 DIN (DIN 477 Anschl. No. 6, W21. 8-14)
MAJ-1082 ISO (ISO 5145 W27 16-16)
Life time 5 years
Item Specification
Tube length 1000 mm
Tube external diameter 9mm
Flow rate Using this tube, the gas flow rate is
approximately equivalent to the airflow pressure
level “High” of the light source.
Item Specification
Tube length 1000 mm
Tube external diameter 9mm
Flow rate Using this tube, the gas flow rate is
approximately equivalent to the airflow pressure
level “Medium” of the light source.
Item Specification
Tube length 1000 mm
Tube external diameter 9mm
Flow rate Using this tube, the gas flow rate is
approximately equivalent to the airflow pressure
level “Low” of the light source.
