Issue 20 : July 2012
WM--P1 SERIES WORKSTATIONS
MAJ- 193 LOCKABLE DRAWER (STANDARD) p/ no K10001118
MAJ- 194 LOCKABLE DRAWER (DEEP) p/no K10001119
MAJ- 1611 LOCKABLE DRAWER (WIDE) p/no K10001383
MAJ- 1612 LOCKABLE DRAWER WIDE DEEP p/no K10001384
Item Description Part No Qty
Torque
Remarks
1 DRAWEROUTER ................................ -- 1 -- E
2 DRAWERSHALLOW--WELDED ...................... -- 1 -- E
3 SLIDETELESCOPIC .............................. K3920693 2 -- A, B, C, D
4 CAMLOCK 1335032A 2 KEY TO PASS ................. K3921294 1 -- A, B, C, D
5 NUTM4 ........................................ 3038114 6 -- A, B, C, D
6 NUTM5 ........................................ 3038410 4 -- A, B, C, D
7 SCREWM8x16HEXSKTCAPHD .................... K3921515 4 -- A, B, C, D
8 SCREWM5x12BUTTHDSKTST.ST .................. 3108601 4 -- A, B, C, D
9 WASHER24ODx8.4IDx2MMTHK ................... K3921536 4 -- A, B, C, D
10 WASHERM5 .................................... 3071286 4 -- A, B, C, D
11 WASHERCRINKLEM8 ............................ K3920997 4 -- A, B, C, D
12 8--10MMOPENENDEDSPANNER .................... K3921063 1 -- A, B, C, D, NS
13 L--WRENCHBALLDRIVE6MMA/F.................... K3921444 1 -- A, B, C, D, NS
14 ALLENKEY3MMA/F .............................. 3066142 1 -- A, B, C, D, NS
15 INSTRUCTIO NS MAJ193--194 & 1611--1612 ............. K10003550 1 -- A, B, C, D, NS
16 SPARE
17 SPARE
18 LABEL INSERT .................................. K5070306 1 -- A, B, C, D, NS
19 INSTRUCTION MAJ193,194,1611,1612 JP ............... K10003589 1 -- A, B, C, D, NS
20 WASHERCRINKLEM4 ............................ 3920332 12 -- A, B, C, D
21 FINGERPULL ................................... K7502154 1 -- A, B, C, D
22 WASHERM3 .................................... 3071227 3 -- A, B, C, D
23 WASHERM3SINGLECOIL ......................... K10000037 3 -- A, B, C, D
24 SCREW SELF TAPPING DIA 3x8LG PAN HD POZI ........ K3921297 3 -- A, B, C, D
25 SCREWM4x612.9HEXSKTBUTHD.................. 3109135 6 -- A, B, C, D
REMARKS
A Used on MAJ--193 LOCKABLE DRAWER (STANDARD) p/no K10001118
B Used on MAJ--194 LOCKABLE DRAWER (DEEP) p/no K10001119
C Used on MAJ--1611 LOCKABLE DRAWER (WIDE) p/no K10001383
D Used on MAJ--1612 LOCKABLE DRAWER WIDE DEEP p/no K10001384
E Repair by replacing whole accessory
NS Not Shown
