7.1.2.2 B105 B110 B115: Spare parts names and codes
POS. DESCRIPTION Q.TY B105 B110 B115
1
BEARING BOX
1
2001G001
2
GEAR COVER
1
2001L031
3
AISI 316 L DRIVING SHAFT
1
2004B001 2004B002
3
DUPLEX DRIVING SHAFT
1
2004D001 2004D002
3
AISI 316 L DOUBLE MECH. SEAL DRIVING SHAFT
1
2004D015 2004D016
4
AISI 316 L DRIVEN SHAFT
1
2004B029 2004B030
4
DUPLEX DRIVEN SHAFT
1
2004D029 2004D030
4
AISI 316 L DOUBLE MECH. SEAL DRIVING SHAFT
1
2004D045 2004D046
5
FIXED GEAR
1
2008M001
6
ADJUSTABLE GEAR
1
2008M007
7
ADJUSTABLE GEAR BUSH
1
2008M031
8
SCREW
6
411F05X14
9
SPLIT RING
2
2001C051
11
AXIAL ADJUSTMENT SPACER
2
2014M024
12
SCREW
4
411A06X16
13
PIN
2
417A06X15
14
SCREW
6
411A06X16S
15
GEAR COVER O-RING
1
404T4437
16
BEARING RETAINER O-RING
2
404T3218
17
OIL SEAL RING
1
403Y26377D
18
OIL SEAL RING
2
403Y35527D
19
KEY
2
418F08X30M
20
KEY
1
418F08X40
23
GEAR RING NUT
2
415F30
24
WASHER
2
416F30
25
OIL VENT CAP
1
407L14S+407L14R
26
OIL CAP
1
407L14T+407L14R
26/1
OIL CAP
1
407L38T+407L38R
27
OIL LEVEL
1
407L38L
28
HORIZONTAL FOOT
1
2001G101
29
FRONT BEARING (ASSEMBLED)
2
2019M001
31
VERTICAL FOOT
2
2001A301
32
SCREW FOR VERTICAL FOOT
8
411A08X20
33
COUNTERFLANGE FOR ENLARGED INLET PORT
1
- - 2006B045
34
O-RING
1
- - 404T3281
40
PUMPING CASE
1
see par. 7.1.5
41
3-LOBE ROTOR S.S.AISI 316 L VERSION ST
1
- 2005B002 2005B003
41
2-LOBE ROTOR S.S.AISI 316 L VERSION ST
2
- 2005B026 2005B027
41
3-LOBE ROTOR S.S.AISI 316 L VERSION SM
2
- 2005B014 2005B015
41
2-LOBE ROTOR S.S. AISI 316 L VERSION SM
2
- 2005B038 2005B039
41
RUBBER COATED 3-LOBE (5-LOBE FOR B105) BUNA-N.B.R.
2
2005B099 - -
41
RUBBER COATED 3-LOBE (5-LOBE FOR B105) E.P.D.M.
2
- 2005B050 2005B051
41
RUBBER COATED 2-LOBE ROTOR BUNA-N.B.R.
2
- - -
41
RUBBER COATED 2-LOBE E.P.D.M.
2
- - -
41
3-LOBE ROTOR CY5SnBIM (ANTISEIZURE) VERSION ST
2
- 2005&002 2005&003
41
DUAL WING CY5SnBIM (ANTISEIZURE) VERSION ST
2
2005&087 2005&074 2005&075
41
GEAR ROTOR S.S.AISI 316 L VERSION ST
2
2005B001 - -
41
GEAR ROTOR CY5SnBIM (ANTISEIZURE) VERSION ST
2
2005&001 - -
42
LOCKING NUT FOR STANDARD ROTOR
2
2004B101
43
LOCKING NUT O-RING
2
404T3100
44
FRONT COVER
2
2006B009 2006B001
