OMAC B430 - Page 85

B105 B110 B115
O.M.A.C. s.r.l.
Via Giovanni Falcone, 8 42048 Rubiera (RE) - Italy Tel.0522/629371 - 629923 Fax 0522/628980
E-mail:info@omacpompe.com SitoWeb:www.omacpompe.com
Chap.7 - pag.
7
Rev.4 del 01/2010 O.M.A.C. s.r.l.
POS. DESCRIPTION Q.TY B105 B110 B115
45
COVER O-RING
2
404T4525
46
BACK STUD
4
419A08X33
47
FRONT STUD
4
419A08X33
48
BACK PIN
2
417A08X20
49
FRONT PIN
2
417A08X16
50
ROTOR O-RING
2
404T2087
51
CAP NUT
4
414A08
52
CAP NUT
4
414A08
53
PLANE WASHER
4
412A08
55
PLANE WASHER
1
412F05
-
COMPLETE SAFETY VALVE
1
2013B001
56
SAFETY VALVE SUPPORT
1
2013L021
56/1
BUSH SAFETY VALVE SUPPORT
1
2013B040
57
SAFETY VALVE PISTON
1
2013B025
58
SAFETY VALVE COVER
1
2013L029
59
SAFETY VALVE ADJUSTMENT SCREW
1
2013B031
60
THRUST WASHER
1
2013L032
61
ADJUSTMEN RING NUT
1
2013A034
62
SAFETY VALVE ADJUSTMENT RETAINER
1
2013L036
63
SAFETY VALVE SCREW
4
411A06X20
64
SAFETY VALVE COVER SCREW
4
411A06X55
65
SCREW
2
420A06X06
66
SPLIT RING (SEEGER)
1
421A38I
67
SPLIT RING (SEEGER)
1
421A16E
68
SAFETY VALVE PISTON O-RING
1
404T4200
69
SAFETY VALVE SUPPORT O-RING
1
404T3250
70
SAFETY VALVE LOCK
1
411A06X10
71
SPRING
1
see par 1.11.6
72
END COVER FOR SAFETY VALVE
1
2006B031
89
FOOT SCREW
4
411A08X20
91
SAFETY VALVE SUPPORT
1
2013B039
92
SCREW
4
411A06X35
93
SUPPORT O-RING
1
404T3250
94
PISTONE VALVOLA DI SICUREZZA PNEUMATICA
1
2013B029
95
KEY
1
418A14X30
96
SAFETY VALVE O-RING
1
404T4200
97
ADJUSTMENT RING NUT
1
2013A034
98
SCREW
2
420A05X06
99
PNEUMATIC SAFETY VALVE COVER
1
2013A032
100
PNEUMATIC SAFETY VALVE COVER BACK O-RING
1
404T4275
101
PNEUMATIC SAFETY VALVE COVER FRONT O-RING
1
404T4312
102
PISTON COVER O-RING
1
404T134
103
PNEUMATIC SAFETY VALVE JACKET
1
2013A035
104
SCREW
4
411A06X110
105
THRUST RING
1
2013L024
106
PISTON ROD THRUST O-RING
1
404T119
107
THRUST JACKET O-RING
1
404T6300
108
RING NUT
2
415F20AUT
111
END COVER FOR HEATING VERSION
1
2006B059 2006B051
112
END COVER FOR ASEPTIC VERSION
1
2006B101
113
END COVER FOR JACKET
1
2006B161
114
SCREW
4
411A06X116 411A06X20
