OMAC B430 - Page 87

B105 B110 B115
O.M.A.C. s.r.l.
Via Giovanni Falcone, 8 42048 Rubiera (RE) - Italy Tel.0522/629371 - 629923 Fax 0522/628980
E-mail:info@omacpompe.com SitoWeb:www.omacpompe.com
Chap.7 - pag.
9
Rev.4 del 01/2010 O.M.A.C. s.r.l.
POS. DESCRIPTION Q.TY
B105 B110
B115
POS. DESCRIPTION Q.TY
B105 B110
B115
200
SEAL STOP PIN
2
2014B200
246
SCREW FOR HN LIP SEAL FLANGE
6
411A05X16
201
SINGLE MECHANICAL SEAL
2
see par. 7.1.2.6
247
PIN FOR HN LIP SEAL FLANGE
4
417A06X10
210
BALANCING RING
2
see par. 7.1.2.5
247
FOR UM LIP SEAL FLANGE
4
-
218
SCREW
6
410A05X10
280
KIT PACKING GLAND IN P.T.F.E.
1
205P38506
220
FLUSHING SEAL BOX
2
2014B141
281
STUFFING BOX SEAL SUPPORT
2
2004B161
221
O-RING
2
404T3218
282
ROTATING BUSH O-RING
2
404T3118
222
SCREW
6
411A05X30
283
SCREW
6
420A05X05
223
SEAL RING UM
2
402V57486
284
STUFFING BOX SEAL SUPPORT
2
2014B071
224
ROTATING RING
2
2004B151
285
FLANGE SUPPORT O-RING
2
404T3218
225
BUSH O-RING
6
404T2137
286
SCREW
3
411A05X14
226
GRANO DI FISSAGGIO ANELLO ROTANTE
6
420A04X05
287
PIN
4
417A06X10
227
SPINA
4
417A06X10
288
PACKING GLAND ADJUSTER
2
2014B101
230
BALANCING RING U7K (SINGLE MECH. SEAL)
2
see par. 7.1.2.5
289
SCREW
2
410A05X16
231
BALANCING RING U7K
(DOUBLE MECH. SEAL)
2
see par. 7.1.2.5
290
KIT PACKING GLAND IN P.T.F.E. WITH LIQUID
BARRIER
1
201P38506
232
O-RING
2
404T3218
291
FLUSHED STUFFING BOX SEAL SUPPORT
2
2014B077
233
SCREW
6
411A05X40
292
HYDRAULIC RING
2
2014B121
234
BEARING BOX FOR DOUBLE SEALS
1
2001G161
295
SPACER
2
-
235
FLUSHING BOX FOR DOUBLE SEAL
2
2014B147
296
MECHANICAL SEAL SUPPORT
2
-
236
COVER
2
2014B153
297
SUPPORT O-RING
2
-
237
SCREW
4
410A05X16
298
SCREW
4
-
238
O-RING
2
404T3218
299
PIN
2
430A05X10
239
SEAL PROTECTION
2
4034Y001
243
UM / S1 PIN
6
420A05X05
240
UM LIP SEAL IN °VITON (F.K.M.)
4
402V45356
243
HN PIN
6
420A05X05
240
UM LIP SEAL IN E.P.D.M.
4
402U45356
244
UM SUPPORT
2
2014B051
240
S1 LIP SEAL
2
402Q45357
244
S1 SUPPORT
2
2014B061
240
DOUBLE HN LIP SEAL
4
402HN40558
244
HN SUPPORT
2
2014B111
240
DOUBLE HN HEAT-SEALED
4
402HN40558SPE
245
UM O-RING SUPPORT
2
404T3218
241
ROTATING BUSH FOR UM / S1 LIP SEAL
2
2004B156
245
HN O-RING SUPPORT
2
404T3218
241
ROTATING BUSH FOR HN SEAL
2
2004B191
246
UM SUPPORTSCREW
6
411A05X14
242
BUSH O-RING FOR UM / S1 LIP SEAL
2
404T3118
246
S1 SUPPORT SCREW
6
411A05X10
242
BUSH O-RING FOR HN LIP SEAL
2
404T3118
7.1.2.4 B105 B110 B115: Gasket or ring codes for mechanical seals
MECHANICAL SEAL
MATERIALS
B105 110 B115
DIAMETER 30
S.S.AISI 316 L
CARBON
TUNGST. CARB.
CARBON
TUNGST. CARB. TUNGST. CARB.
CERAMIC
CARBON
SILICON CARB.
CARBON
CERAMIC
RULON
SILICON CARB. SILICON CARB.
CARB. SILICIO
TUNGST. CARB.
ROTATING O-RING
U7K - KL2A - C5E
404U4118 404U4118 404U4118
404U4118
(1)
-
404U4118
(2)
404U4118
(3)
404U4118
(3)
STATIONARY O-RING
U7K - KL2A - C5E
404U4150 404U4150 404U4150
404U4150
(1)
-
404U4150
(2)
404U4150
(3)
404U4150
(3)
(1)ONLY KL2A, C5E (2)ONLY C5E (3)ONLY KL2A
