7.1.3.2 B215 B220 B325 B330 B390 B430 B440 B470 B490: Spare parts names and codes
POS DESCRIPTION Q.TY B215 B220 B325 B330 B390 B430 B440 B470 B490
1
BEARING BOX
1
2001G002 2001G003 2001G004 2001G008
2
GEAR COVER
1
2001L032 2001L033 2001L034 2001L038
3
AISI 316 L DRIVING SHAFT
1
2004B003 2004B004 2004B005 2004B006 2004B007 2004B008 2004B063 2004B065
3
DUPLEX DRIVING SHAFT
1
2004D003 2004D004 2004D005 2004D006 2004D007 2004D008 2004D009 2004D010
3
AISI 316 L DOUBLE MECH. SEAL DRIVING SHAFT
1
2004D017 2004D018 2004D019 2004D020 - 2004D021 2004D022 2004D023 2004D024
4
AISI 316 L DRIVEN SHAFT
1
2004B031 2004B032 2004B033 2004B034 2004B035 2004B036 2004B064 2004B066
4
DUPLEX DRIVEN SHAFT
1
2004D031 2004D032 2004D033 2004D034 2004D035 2004D036 2004D037 2004D038
4
AISI 316 L DOUBLE MECH. SEAL DRIVING SHAFT
1
2004D047 2004D048 2004D049 2004D050 - 2004D051 2004D052 2004D053 2004D054
5
FIXED GEAR
1
2008M002 2008M003 2008M004 2004M014
6
ADJUSTABLE GEAR
1
2008M008 2008M009 2008M010 2008M015
7
ADJUSTABLE GEAR BUSH
1
2008M032 2008M033 2008M034 2008M037
8
SCREW
6
411A06X16 411A08X20 411A10X25 411A10X30
9
SPLIT RING
2
2001C052 2001C053 2001C054 2001C057
10
REAR AXIAL ADJUSTMENT SPACER
2
2014M021 - - - - - - -
11
FRONT AXIAL ADJUSTMENT SPACER
2
2014M025 2014M026 2014M027 2014M044
12
SCREW
4
411A08X20 411A08X25 411A10X30 411A10X30
13
PIN
2
417A06X14 417A06X16 417A06X16 417A08X16
14
SCREW
6
411A08X20S 411A08X20S 411A10X25S 411A10X25S
15
GEAR COVER O-RING
1
404T4562 404T4675 404T4900 404T81050
16
BEARING RETAINER O-RING
2
404T3268 404T4312 404T4437 404T4500
17
OIL SEAL RING
1
403Y32457 403Y37528 403Y557210D 403Y658510D
18
OIL SEAL RING
2
403Y45608D 403Y60758D 403Y801008D 403Y9011012D
19
KEY
2
418F10X30M 418F12X40M 418F18X50M 418F20X60M
20
KEY
1
418F08X40 418F10X50 418F14X70 418F16X90
21 BEARING RING NUT 2
415F40 415F50 415F70 415F80
22 WASHER 2
416F40 416F50 416F70 416F80
23
GEAR RING NUT
2
415F35 415F40 415F60 415F70
24
WASHER
2
416F35 416F40 416F60 416F70
25
OIL VENT CAP
1
407L12S 407L12S 407L12S 407L12S
26
OIL CAP
1
407L12T 407L12T 407L12T 407L12T
27
OIL LEVEL
1
407L12L 407L12L 407L12L 407L12L
28
HORIZONTAL FOOT
1
2001G102 2001G103 2001G104 2001G105
29
FRONT BEARING (ASSEMBLED)
2
2019M002 2019M003 2019M004 2019M008
30
REAR BEARING (ASSEMBLED)
2
2019M005 2019M002 2019M007 2019M004
