OMAC B430 - Page 91

B2 B3 B4 B470 B490
O.M.A.C. s.r.l.
Via Giovanni Falcone, 8 42048 Rubiera (RE) - Italy Tel.0522/629371 - 629923 Fax 0522/628980
E-mail:info@omacpompe.com SitoWeb:www.omacpompe.com
Chap.7 - pag.
13
Rev.4 del 01/2010 O.M.A.C. s.r.l.
POS DESCRIPTION Q.TY B215 B220 B325 B330 B390 B430 B440 B470 B490
31
VERTICAL FOOT
2
2001A302 2001A303 2001A304 2001A305
32
SCREW FOR VERTICAL FOOT
8
411A10X20 411A12X25 411A14X30 411A20X40
33
COUNTERFLANGE FOR ENLARGED INLET PORT
1
- 2006B046 - 2006B047 - - 2006B048 - 2006B049
34
O-RING
1
- 404T4350 - 404T4500 - - 404T4650 - 404T4725
40
PUMPING CASE
1
23....04 23....05 23....06 23....07 23....17 23....08 23....09 23....15 23....16
41 3-LOBE ROTOR S.S. AISI 316 L VERSIONE ST 1
2005B004 2005B005 2005B006 2005B007 2005B096 2005B008 2005B009 2005B090 2005B092
41 2-LOBE S.S. AISI 316 L VERSION ST 2
2005B028 2005B029 2005B030 2005B031 - 2005B032 2005B033 2005B094 2005B095
41 3-LOBE ROTOR S.S. AISI 316 L VERSIONE SM 2
2005B016 2005B017 2005B018 2005B019 - 2005B020 2005B021 2005B046 2005B047
41 2-LOBE S.S. AISI 316 L VERSION SM 2
2005B040 2005B041 2005B042 2005B043 - 2005B044 2005B045 2005B048 2005B049
41
3-LOBE ROTOR (5-LOBE FOR B105) RUBBER COATED N.B.R.
2
2005B052 2005B053 2005B054 2005B055 - 2005B056 2005B057 - -
41
3-LOBE ROTOR (5-LOBE FOR B105) RUBBER COATED E.P.D.M.
2
- - - - - - - - -
41 2-LOBE ROTOR RUBBER COATED N.B.R. 2
2005B064 2005B065 2005B066 2005B067 - 2005B068 2005B069 2005B096 2005B097
41 2-LOBE ROTOR RUBBER COATED E.P.D.M. 2
- - - - - - - - -
41 DUAL WING CY5SnBIM (antiseizure) VERSION ST 2
2005&076 2005&77 2005&078 2005&079 - 2005&080 2005&081 2005&082 2005&083
41 3-LOBE ROTOR CY5SnBIM (antiseizure) VERSION ST 2
2005&004 2005&005 2005&006 2005&007 - 2005&008 2005&009 - -
42
LOCKING NUT FOR STANDARD ROTOR
2
2004B102 2004B103 2004B125 2004B104 2004B104
43
LOCKING NUT O-RING
2
404T3118 404T3162 404T3162 404T3200 404T3200
44
FRONT COVER
2
2006B002 2006B003 2006B004 2006B008
45
COVER O-RING
2
404T4625 404T4750 404T81025 404T81175
46
BACK STUD
4
419A10X41 419A12X46 419A16X55 419A20X70
47
FRONT STUD
4(*)-8
419A10X41(*) 419A10X41 419A12X46 419A14X55
48
BACK PIN
2
417A10X20 417A12X25 417A12X25 417A16X40
49
FRONT PIN
2
417A08X16 417A08X16 417A08X16 417A10X20
50
ROTOR O-RING
2
404T2106 404T3143 4043187 407T3187
51
CAP NUT
4(*)-8
414A10(*) 414A10 414A12 414A14
52
CAP NUT
4
414A10 414A12 414A16 414A20
53
PLANE WASHER
4
412A10 412A12 412A16 412A20
55
PLANE WASHER
12
412F06 412F08 412F10 412F10
-
COMPLETE SAFETY VALVE
6
2013B002 2013B003 2013B004 2013B021
56
SAFETY VALVE SUPPORT
1
2013L021 2013L022 2013L023 2013B047
56/1
BUSH SAFETY VALVE SUPPORT
1
2013B040 2013B041 2013B042 2013B042
57
SAFETY VALVE PISTON
1
2013B026 2013B027 2013B028 2013B048
