POS DESCRIPTION Q.TY B215 B220 B325 B330 B390 B430 B440 B470 B490
58
SAFETY VALVE COVER
1
2013L029 2013L029 2013L030 2013A027
59
SAFETY VALVE ADJUSTMENT SCREW
1
2013B031 2013B031 2013B031 2013A028
60
THRUST WASHER
1
2013L032 2013L032 2013L033 2013A026
61
ADJUSTMEN RING NUT
1
2013A034 2013A034 2013A035 2013A038
62
SAFETY VALVE ADJUSTMENT RETAINER
1
2013L036 2013L036 2013L036 2013A025
63
SAFETY VALVE SCREW
1
411A06X20 411A08X35 411A10X40 411A08X50
64
SAFETY VALVE COVER SCREW
4
411A06X55 411A06X55 411A08X60 411A08X70
65
SCREW
4
420A06X06 420A06X06 420A06X06 420A06X06
66
SPLIT RING (SEEGER)
2
421A38I 421A38I 421A52I 421A63I
67
SPLIT RING (SEEGER)
1
421A16E 421A16E 421A16E 421A34E
68
SAFETY VALVE PISTON O-RING
1
404T4200 404T6275 404T189 404T208
69
SAFETY VALVE SUPPORT O-RING
1
404T3250 404T4337 404T4462 404T4600
70
SAFETY VALVE LOCK
1
41106X10 411A06X10 411A06X10 418A20X56
71
SPRING
1
see par. 7.1.6
72
END COVER FOR SAFETY VALVE
1
2006B032 2006B033 2006B034 2006B029
89
FOOT SCREW
4
411A10X25 411A12X35 411A14X35 411A20X50
91
SAFETY VALVE SUPPORT
1
2013B039 2013B032 2013B036 2013B043
92
SCREW
4
411A06X35 411A08X40 411A10X40 411A08X40
93
SUPPORT O-RING
1
404T3250 404T4337 404T4462 404T4600
94
PISTONE VALVOLA DI SICUREZZA PNEUMATICA
1
2013B030 2013B035 2013B038 2013B045
95
KEY
1
418A14X30 418A14X30 418A14X30 418A18X50
96
SAFETY VALVE O-RING
1
404T4200 404T6275 404T189 404T208
97
ADJUSTMENT RING NUT
1
2013A034 2013A034 2013A034 2013A038
98
SCREW
2
420A05X06 420A05X06 420A05X06 420A06X08
99
PNEUMATIC SAFETY VALVE COVER
1
2013A032 2013A030 2013A031 2013A029
100
PNEUMATIC SAFETY VALVE COVER BACK O-RING
1
404T4275 404T4275 404T4312 404T4425
101
PNEUM. SAFETY VALVE COVER FRONT O-RING
1
404T4312 404T4312 404T4475 404T4600
102
PISTON COVER O-RING
1
404T134 404T134 404T134 404T4131
103
PNEUMATIC SAFETY VALVE JACKET
1
2013A035 2013A036 2013A037 2013A039
104
SCREW
4-6(*)
411A06X110 411A08X130 411A10X130 411A08X130(*)
105
THRUST RING
1
2013L024 2013L024 2013L025 2013L026
106
PISTON ROD THRUST O-RING
1
404T119 404T119 404T119 404T4075
107
THRUST JACKET O-RING
1
404T6300 404T6300 404T8450 404T8562
108
RING NUT
2
415F20AUT 415F20AUT 415F20AUT 415F25AUT
