L1120E1IENS002 24
12.1.
Spare parts list
EN
REF. NAME
45 Pump cylinder
46 Bleed valve and oil injection
47 Gasket for bleed valve
48 Pumping piston
49 Piston gasket
50 OR rings for cylinder
52 Piston return spring
53 Cylinder
54 OR ring
55 Piston gasket
56 Gasket holder and runner
57 Piston
58 OR ring
59 Spring plug
60 OR rings
61 Copper gasket
62 Ball pressing spring
63 OR ring
64 Snap ring
65 OR ring
66 Pedal pin
67 Snap ring
68 Drain valve press
69 Dowel for valve press
70 OR ring
71 Pin for drawbar
72 Snap ring
73 Oil filter
74 Pump support pin
75 Pump
76 Cap
77 Slider
78 OR ring
79 Spring
80 Ball press
81 Max. pressure ball
82 Instruction manual
83 Complete set of adhesives
84 Name plate
REF. NAME
1 Handle
3 Handle hub
4 Handle setscrew
6 Piston pin
8 Piston pin bush
9 Wheel fastening screws and nut
10 Articulated wheel
12 Pump
13 Stop ring
14 Arm return spring
15 Arm
16 Connecting-rod for arm
17 Plate holder
18 Plate
19 Plate setscrew
20 Articulated joint washer
21 Connecting-rod stop nuts
22 Pedal
23 Arm support pin
24 Washer for screws
25 Screws for fastening pin
26 Stop rings
27 Truck
28 Fastening screws for front wheels
29 Washer
30 Front wheels
31 Stop ring
32 Pin for controlling drain valve
33 OR rings
34 Drain valve plug
35 Spring
36 Drain valve unit
37 OR ring
38 Ball
39 Spring
40 Plug for fastening spring
41 Plug gasket
42 Plug for ball unit
43 Check valve ball
44 Suction valve ball
