OMPHOBBY M4 - ESC, FC, Battery Installation; Canopy Installation

4-4 ESC, FC, Battery installation
FC (× 1)
FC Mounting Pad (× 1)
M4-404
FC ( × 1)
Damping sticker (× 1)
19
WWW.OMPHOBBY.COM
Installation steps 安装步骤
4-5 Canopy Installation allation
M4-405
Canopy Rubber
Grommet (× 2)
Canopy (× 1)
Canopy (× 1)
Canopy Rubber Grommet (× 2)
※ Recommended battery weight: 295-330g
Possible max battery dimensions in mm:
35x40x160 35x43x140
35x46x130 35x48x120
35x50x110 35x53x90
35x55x70
