Servo & Motor Spec 舵机与电机参数
22
Servo Spec
ESC 65A Specification
Continuous/Peak current
Input voltage
BEC
Input/output wire
Size/Weight
3-6S Lipo HV
6V/7.4V/ 8.4V , 10A
1x Black & 1x Red 10AWG Silicon wire / 3x Black 10AWG Silicon wire.
60x36x18.5mm / 65g
65A/100A
1. Throttle signal/BEC output wire (Black, Red, White): Plugs into the receiver
throttle channel. The white wire carries the throttle signal, the red wire and
black wire carry the BEC voltage and ground.
2. RPM signal wire (Yellow): Plug into the RPM input port. (If applicable)
Throttle calibration procedure
Turn on the transmitter, move the
throttle stick to the top possition.
Connect the battery to the ESC
and wait for about 2 secs.
The motor will
beep for twice,
then move the
throttle stick to
the bottom
position in 2
Secs.
The motor will beep serceral sounds,
sounds time presents the amount of the
battery cells
When the motor emits
"Beep...Beep", means the
ESC is ready to work.
Wire Connections
(Important:Please make the throttle calibration for the first time using ESC!!!)
OMPHOBBY M4 Micro Tail Servo
Model
Working Frequence：
Connector：
Servo Arm：
Item：
Operating Voltage：
Dead Band：
Stall Current
Operating Speed(no load)：
Torque：
Stall Torque：
Weight
2312T
500-1000us
3P Dupont
5mm 25T
Operating Voltage：
Control System：
Wire length：
Operation Angle：
4.8V-8.4V
PWM
220mm
140 Deg
Spec
7.4V
2u
1.7A
0.053sec/60°
3.5kg.cm
7kg.cm
21g
Model
Working Frequence：
Connector：
Servo Arm：
Item：
Operating Voltage：
Dead Band：
Stall Current
Operating Speed(no load)：
Torque：
Stall Torque ：
2312C
800-2200us
3P Dupont
5mm 25T
Operating Voltage：
Control System：
Wire length：
Operation Angle：
4.8V-8.4V
PWM
220mm
140 Deg
Spec
7.4V
2u
1.7A
0.073sec/60°
4.9kg.cm
9kg.cm
OMPHOBBY M4 Micro cyclic Servo
