B7AM-8j
B7AM-8j
58
Specifications
Characteristics
General
Normal
speed
High speed
Communications method
Unidirectional, time-division multiplex
T
ransmission distance (see note 1)
500 m max.
100 m max. (see note 2)
I/O delay time
T
ypical: 19.2 ms; 31 ms max.
T
ypical: 3 ms; 5 ms max.
Minimum input time (see note 3)
16 ms
2.4 ms
Operating voltage range
12 to 24 VDC (10.8 to 26.4 VDC) (see note 1)
Insulation resistance
100 M
Ω
min. (500 V) between each terminal and external parts
Dielectric strength
1,000 V
AC, 50/60 Hz for 1 min between each terminal and external parts
Noise immunity (see note 4)
Noise level: 1.5 kV
; pulse width: 100 ns to 1
µ
s (on transmission line due to coupling)
V
ibration resistance
10 to 55 Hz, 1.5-mm double amplitude
Shock resistance
300 m/s
2
Ambient temperature
Operating:
–10 to 55
°
C (with no icing)
Storage:
–25 to 65
°
C (with no icing)
Ambient humidity
Operating: 35% to 85% (with no condensation)
Note: 1. The
transmission distance values stated in this table are possible if the Input or Output Link T
erminal is connected to an independent
power
supply
. If a single power supply is connected to the Input or Output Link T
erminal, the supply voltage must be 24 VDC
±10%,
in which case the transmission distance of a normal-speed model is 100 m maximum and that of a high-speed model is 50 m maxi
-
mum.
2. A
shielded transmission cable or a VCTF cable with a thickness of
0.75 mm
2
minimum must be used for signal transmission. If the
VCTF
cable is used, however
, the transmission distance will be 10 m maximum regardless of whether or not independent power
supplies
for the Input and the Output Link T
erminals are used.
3.
The minimum input time is required for the B7AM to read an input signal.
4.
As for the high-speed model, these values are possible without grounding the shielded line.
