Screw Terminal Models
Item B7AM-8B11/-8B31/-8B16/-8B36 B7AM-8F31
Compatible
inputs
(see note 1)
Switches, two-wire sensors with DC output,
three-wire NPN sensors
Switches, two-wire sensors with DC output,
three-wire PNP sensors
I/O delay time
B7AM-8Bj
1: normal speed (typical 19.2 ms);
B7AM-8Bj
6: high speed (typical 3 ms)
Normal speed (typical 19.2 ms)
Input logic
Active low
Active high
Current consumption
(see note 2)
120 mA max. with all input/output terminals ON
Operating voltage range
12 to 24 VDC
Input voltage range
0 VDC to supply voltage
Input current range
–6 to –3 mA/point (current flowing from input
terminals)
3 to 6 mA/point (current flowing from input
terminals)
Minimum input time
B7AM-8Bj
1: 16 ms; B7AM-8B
j
6: 2.4 ms
ON/OFF threshold
No-contact input:
ON voltage:
4 V max.
OFF voltage:
6 V min.
Contact input:
ON discrimination resistance:
660
Ω
max.
OFF discrimination resistance:
2 kΩ
min.
Output configuration
NPN open collector
PNP open collector
Rated load voltage
5 to 24 VDC
Output residual voltage
0.8 V max.
Output current
Sync. current, 100 mA max./ point
Error processing
B7AM-8B1j
: HOLD; B7AM-8B3
j: LOAD OFF LOAD OFF
Mounting strength
No damage when 49-N pull is applied for 1 min each in all directions
T
erminal strength
No damage when 49-N pull is applied for 1 min each in all directions
T
ightening torque
0.78 to 1.18 N
S
m
Weight
Approx. 140 g
Note: 1.
Power must be supplied to the three-wire sensor via the positive power supply terminal or from an independent power supply
.
T
wo-wire sensors must satisfy the following requirements:
Residual voltage:
4 V max.
Current leakage: 1.5 mA max.
The lower limit of control output:
3 mA (Use a bleeder resister to eliminate this restriction.)
2. Consumption
when all 8 input/output points are ON. Excludes external sensor current for Input T
erminals and external load
current
and
error load current for Output T
erminals.
