2.Installation and connection
17
2-4 Connecting the AC input
When installation and connection are complete, connect the unit’s AC input to a commercial power
source.
Make sure to connect the AC input plug of the unit into a wall outlet
(commercial power) with rated input voltage (100V to 120V AC).
●
Connectingtoawalloutlet(commercialpower)ofadifferentratedvoltagemayresultinre.
●
The unit may fail.
When the maximum output capacity (1500VA/1350W) is connected to the
BN150R, replace the AC input plug with a 20A plug. When the maximum
output capacity (3000VA/2700W) is connected to the BN300R, change to
terminal block connection.
●
Overheatingorremayoccurifthepowerconsumptionexceedsthelimitsshowninthetable
above.
●
If the maximum output capacity is being used, change the AC input connection method by refer-
ring to the table above.
●
After changing the AC input plug, change the “Setting” - “In/Out Settings” - “Input Plug” setting
in the menu on the LCD.
Caution
Caution
●
The BN75R AC input plug cannot be changed.
●
The AC input plug for the BN150R and BN300R can be changed according to the operating
environment.
●
The supported AC input plugs and the maximum connection capacities are as follows.
Change to an appropriate AC input plug according to the connection capacity of the device.
Model AC input plug Voltage sensitivity setting Maximum connection capacity
BN75R 15A Low 750VA/680W
Standard/High 750VA/680W
BN150R 15A (attached when shipped) Low 1050VA/1050W
Standard/High 1125VA/1125W
20A Low 1450VA/1350W
Standard/High 1500VA/1350W
BN300R 20A Low 1420VA/1420W
Standard/High 1520VA/1520W
30A (attached when shipped) Low 2220VA/2220W
Standard/High 2370VA/2370W
Terminal block connection Low 3000VA/2700W
Standard/High 3000VA/2700W
* The bold font indicates factory settings.
