113
Expanded System Configuration Section 2-5
Note 1. The Peripheral Bus Mode is used for Programming Devices excluding Pro-
gramming Console. If Programming Console is to be used, set pin 4 of the
DIP switch on the front panel of the Unit to OFF so that the default periph-
eral port communications parameters are used instead of those specified
in the PLC Setup.
2. CPU Unit with version 3.0 or later (peripheral port and RS-232C port) and
Serial Communications Board/Unit with unit version 1.2 or later only.
3. Serial Communications Board/Unit with unit version 1.2 or later only.
Host Link System
(SYSMAC WAY Mode 1:N)
The Host Link System allows the I/O memory of the PLC to be read/written,
and the operating mode to be changed from a Host computer (personal com-
puter or Programmable Terminal) by executing Host Link commands or FINS
commands that are preceded by a header and followed by a terminator. Alter-
natively, FINS commands (preceded by a header and followed by a termina-
tor) can be sent to a computer connected via the Host Link System by
executing Network Communications Instructions (SEND(090)/RECV(098)/
CMND(490)) from the PLC.
NT Links (1: N) OMRON Programmable Ter-
minals
High-speed communica-
tions with Programmable
Terminals via direct access.
None
Peripheral bus (See note 1.) Programming Devices CX-
Programmer
Communications between
Programming Devices and
the PLC from the computer.
None
Serial Gateway OMRON Component
PLC
Converts FINS commands
that are received into Com-
poWay/F, Modbus, or Host
Link protocols, and then
transmits the converted com-
mand to the serial line.
CompoWay/F Master
(See note 2.)
CompoWay/F slave Converts FINS commands
(encapsulated CompoWay/F
commands) received at the
serial port into CompoWay/F
commands.
FINS command
2803 hex received
(including sending FINS
command using
CMND(490))
Modbus Master (See
note 3.)
Modbus slave Converts FINS commands
(encapsulated Modbus com-
mands) received at the serial
port into Modbus commands.
FINS command
2804 hex or 2805 hex
received
(including sending FINS
command using
CMND(490))
Host Link FINS
(SYSWAY) Master (See
note 3.)
Host Link FINS (SYSWAY)
slave (PLC)
Converts FINS commands
into FINS commands encap-
sulated in Host Link
Any FINS command
received except those sent
to serial port
(including sending FINS
command using
CMND(490))
Protocol Main connection Use Applicable commands,
communications
instructions
To Next Page
