Omron CJ1G/H-CPU series User Manual

118
Expanded System Configuration Section 2-5
Host Link FINS
Unit/Protocol Compatibility
Note 1. The Peripheral Bus Mode is used for Programming Devices excluding Pro-
gramming Consoles. If Programming Console is to be used, set pin 4 of the
DIP switch on the front panel of the Unit to OFF so that the communica-
tions settings are automatically detected instead of using those specified
in the PLC Setup.
2. Supported for CPU Units with unit version 3.0 or later and Serial Commu-
nications Boards/Units with unit version 1.2 or later only. For CPU Units,
however, only automatic CompoWay/F connection is possible.
Host Link System Slave
The following system configurations are possible for a Host Link System.
C-mode Commands
Unit Model Port Periph-
eral bus
(See
note.)
Host
Link
No-proto-
col (cus-
tomer)
communi-
cations
Proto-
col
macro
NT Link
(1:N
Mode)
Serial
Gate-
way (See
note 2.)
CPU Units CJ1G/H-
CPU@@H
CJ1M-CPU@@
CJ1G-
CPU@@
Peripheral Yes Yes --- --- Yes Yes
RS-232C Yes Yes Yes --- Yes Yes
Serial
Communications
Unit
CJ1W-SCU41
CJ1W-SCU21
RS-422A/485 --- Yes Yes (See
note 2.)
Ye s Ye s Ye s
RS-232C --- Yes Yes (See
note 2.)
Ye s Ye s Ye s
CMND(490)
FINS
FINS
FINS
FINS
Network
PLC (Host Link slave)
PLC (Host Link Master)
Serial Communications
Board/Unit with unit
version 1.2 or later
Note: Not supported
for CPU Units
Serial
Gateway
Host Link
header
Host Link
terminator
FINS command
sent
Host Link
header
Host Link
terminator
CX-Programmer or other
Programming Device that
uses CX-Server as the
communications driver
Host Link
Host Link commands
