xvii
Current Consumption and
Weight
Common Processing Time
(Overhead Time)
Battery Backup Time At 25
°C, the battery life (maximum service life) for batteries is five years
whether or not power is supplied to the CPU Unit while the battery is installed.
This is the same as for CJ1G-CPU@@H CPU Units. The following table shows
the approximate minimum lifetimes and typical lifetimes for the backup battery
(total time with power not supplied).
Note The minimum lifetime is the memory backup time at an ambient temperature
of 55
°C. The typical lifetime is the memory backup time at an ambient temper-
ature of 25
°C.
EXEC Running Green Not lit The system is stopped for one of the following reasons:
• The Loop Control Board is initializing.
• A hardware failure occurred in the Loop Control Board.
• Power is not being supplied from the Power Supply Unit.
• A Loop Control Board WDT error occurred.
• The Loop Control Board is not running.
• Data is being written to flash memory.
Flashing
(at 0.5-s
intervals)
Erasing flash memory.
Flashing
(0.2-s
intervals)
Backup operation to function block flash memory in
progress
Lit The Loop Control Board is not running.
Indicator Name Color Status Description
Product name and model Current consumption Weight
CJ1G-CPU45P/44P/43P/42P
Loop-control CPU Unit
1.06 A 220 g max.
CJ1G-CPU45H/44H/43H/42H
CJ1-H CPU Unit (reference)
0.91 A 190 g max.
Product name and model Common processing time
CJ1G-CPU45P/44P/43P/42P
Loop-control CPU Unit
0.8 ms max.
CJ1G-CPU45H/44H/43H/42H
CJ1-H CPU Unit (reference)
0.3 ms
Model Approx.
maximum
lifetime
Approx.
minimum
lifetime
(See note.)
Typical lifetime
(See note.)
CJ1G-CPU45P/44P/43P/42P
Loop-control CPU Unit
5 years 5,600 hours
(approximately
0.64 years)
43,000 hours
(approximately 5
years)
CJ1G-CPU45H/44H/43H/42H
CJ1-H CPU Unit (reference)
5 years 6,500 hours
(approximately
0.75 years)
43,000 hours
(approximately 5
years)
