179

CJ-series Basic I/O Units Section 3-6

Connecting to

I/O Terminals

The CJ-series 32/64-point Basic I/O Units can be connected to I/O Terminals

as shown in the following table.

Units with Fujitsu-compatible Connectors

CJ1W-

MD263

32-point 24-V DC

Input/32-point Tran-

sistor Output Unit

with Sinking Outputs

Inputs:

XW2Z-@@@K

XW2B-40G4 Standard, M3 screw terminal block 1 Connecting Cable

and 1 Conversion Unit

XW2B-40G5 Standard, M3.5 screw terminal block

XW2D-40G6 Slim, M3 screw terminal block

XW2D-40G6-RM Slim, M3 screw terminal block, built-

in bleeder resistor

Inputs:

XW2Z-@@@N

XW2C-20G5-IN16 16-point input common, M3.5 screw

terminal block

1 Connecting Cable

and 2 Conversion Units

XW2C-20G6-IO16 16-point I/O common, M3.5 screw

terminal block

Outputs:

XW2Z-@@@K

XW2B-40G4 Standard, M3 screw terminal block 1 Connecting Cable

and 1 Conversion Unit

XW2B-40G5 Standard, M3.5 screw terminal block

XW2D-40G6 Slim, M3 screw terminal block

Outputs:

XW2Z-@@@N

XW2C-20G6-IO16 16-point I/O common, M3 screw ter-

minal block

1 Connecting Cable

and 2 Conversion Units

CJ1W-

MD563

32-point TTL Input/

32-point TTL Output

Unit

Inputs:

XW2Z-@@@K

XW2B-40G4 Standard, M3 screw terminal block 1 Connecting Cable

and 1 Conversion Unit

XW2B-40G5 Standard, M3.5 screw terminal block

XW2D-40G6 Slim, M3 screw terminal block

Inputs:

XW2Z-@@@N

XW2C-20G5-IN16 16-point input common, M3.5 screw

terminal block

1 Connecting Cable

and 2 Conversion Units

XW2C-20G6-IO16 16-point I/O common, M3.5 screw

terminal block

Outputs:

XW2Z-@@@K

XW2B-40G4 Standard, M3 screw terminal block 1 Connecting Cable

and 1 Conversion Unit

XW2B-40G5 Standard, M3.5 screw terminal block

XW2D-40G6 Slim, M3 screw terminal block

Outputs:

XW2Z-@@@N

XW2C-20G6-IO16 16-point I/O common, M3.5 screw

terminal block

1 Connecting Cable

and 2 Conversion Units

Basic I/O Unit Connecting

Cable

Connector-Terminal Block Conversion Unit Required for

connection

Model

number

Specifications Model number Specifications

Basic I/O Unit Connecting

Cable

I/O Terminal Required for

connection

Model

number

Specifications Model number Type Input voltage/

output type

CJ1W-

ID231

32-point 24-V DC Input

Unit

G79-I@C-@ G7TC-ID16 Input Block Input: 24 V DC

Output: Relay

1 Connecting Cable

and 2 I/O Terminals

G7TC-IA16 Input: 100/

200 V AC

Output: Relay

CJ1W-

ID261

64-point 24-V DC Input

Unit

G79-I@C-@ G7TC-ID16 Input: 24 V DC

Output: Relay

2 Connecting Cables

and 4 I/O Terminals

G7TC-IA16 Input: 100/

200 V AC

Output: Relay

CJ1W-

OD231

32-point Transistor Out-

put Unit with Sinking

Outputs

G79-O@C-@ G7TC-OC16 Output Block Input: 24 V DC

Output: Relay

1 Connecting Cable

and 2 I/O Terminals

G70D-SOC16/

VSOC16

Output Termi-

nal (Slim)

Input: 24 V DC

Output: Relay

G70D-FOM16/

VFOM16

Output Termi-

nal (Slim)

Input: 24 V DC

Output: MOS FET

G70A-ZOC16-3 +

Relays

Relay Terminal

Socket (NPN) +

Relays

Input: 24 V DC

Output: Mechani-

cal relay, SSR,

MOS FET (via

relay)
